Description
Additional Features:
- SMA JACK (F) TO JACK (F), PANEL
- High bandwidth, small size, and durability for confident connections
- DC – 18 GHz
- Meets MIL-C-39012, IEC 169-15, CECC 22110.
- Small size and durability for mobile communications
- Precision machined and gold-plated for low loss
Materials
- Body is machined brass with gold plating
- Center Contacts – Plug is gold plated brass and Jack is gold plated Beryllium copper
- Insulators are high quality PTFE
- Crimp Ferrules are copper with gold or nickel plating
- Gaskets are silicone rubber
Specifications
- Impedance: 50 Ω
- Frequency Range: DC –18 GHz max.
- Working Voltage: < 500 Vpeak
- Dielectric Withstanding Voltage: 1,000 Vrms
- VSWR: 1.25 max
- Center/Outer Contact Resistance: 0.003/0.002 Ω max
- Insulation resistance: > 5000 MΩ
The Pomona 72973 is a panel mount SMA jack to SMA jack Straight Adapter. The 72973 features high bandwidth, small size and durability for confident connections. Precision machined and gold-plated for low loss. Gold plated brass center contacts for plug and gold plated beryllium copper center contact for jack.
