Agilent N2874A 1.5 Ghz Passive Voltage Probe – Used, High Accuracy

Description

Additional Features:

• 1.5 GHz bandwidth
• 10:1 attenuation ratio
• 2 pF input capacitance
• 500 Ohm input resistance (when terminated into 50 Ohm scope input)
• 8.5V CAT I maximum input voltage

The N2874A passive probe offers DC to 1.5 GHz and 10:1 attenuation factor to measure fast edges in high speed applications more accurately. This probe needs 50 Ohm input on the oscilloscope.

Compact 2.5-mm probe head diameter, low input capacitance, and various fine-pitch probe tip accessories make the N2874A passive probes ideal for probing densely populated IC components or surface-mount devices used in today’s high-speed digital applications.

The sharp probe tip is spring loaded to help engineers keep the probe from slipping off the device under test. Insulating IC caps keep the small probe tip centered on the IC lead and keep it from shorting adjacent leads. Standard flat blade ground connector and self-adhesive copper ground pad help reduce ground inductance while offering easy ground access. Optional probe tip accessories provide specialized capabilities for demanding applications.

Compatible with Agilent InfiniiVision and Infiniium Series oscilloscopes with 50 Ohm input. Recommended for measuring 50 Ohm transmission line or signals with low source impedance (<50 Ohm).
