Agilent N7752A Programmable Optical Attenuator – Used & Verified

Description

Additional Features:

Measurement capability: attenuator

• Settling time: 20 ms attenuation, 100 ms power
• 0.1 to 1000 dB/s attenuation transition speed (selectable)
• +23 dBm input power
• ≤ 1.2 dB insertion loss

Measurement capability: power meter

• Wavelength range: 1260-1640 nm
• Power range: -80 to +10 dBm
• Polarization dependence: <0.01 dB

System capability

• Two attenuator channels and two power meters in one half-width rack unit
• Fully compatible with programs developed using the Keysight 8157x and 8156x modular attenuators
• Includes powerful and user-friendly GUI software
• Two instrument configurations can be stored and recalled

Applications

• Optical transceiver testing
• Optical network integration testing

The Agilent N7752A combines an attenuator with 2 front-panel power meter channels, offering exceptional performance at a low price. The power meters permit measurements from any point in the measurements setup and assist in calibrating power offsets with respect to the attenuator output.
