Description
Additional Features:
- Voltage: 0-40V
- Current: 0-13A
- Power: 500W
- 115 VAC single phase input standard
- 50/60 Hz operation without derating
- 0.03% line and load regulation (typical)
- 90mV RMS ripple
- 50 ms transient response – 50% load change (typical)
- Low-Level Remote Sensing
- Manual & Automatic Control
- Direct & Master-Slave Paralleling & Series Operation
- 19″ Rack Mountable
- Low Ripple and Noise
- Amperage and Voltage Meters
- Excellent voltage and current regulation with automatic crossover; panel lights indicate operating mode
- Remote voltage and resistance programming for both voltage and current modes standard
- Adjustable current limiting (overload/short circuit protection) with automatic recovery
- Overvoltage protection with crowbar standard on all models
The Sorensen DCR40-13B2 is a member of the 500W DCR-B2 family of general purpose, rackmount power supplies. The DCR40-13B2 operates at a voltage range of 0-40V and a current of 13 Amps.
The DCR40-13B2, high power programmable power supplies have input SCR preregulator topology plus regulation and transient response performance suitable for nearly all test and measurement applications. The DCR40-13B2 operates from a nominal 115 VAC and exhibits a rapid response to transients, both load and line.
