Description
Features
- 17mm diameter camera head with 39″ (1m) flexible gooseneck cable retains configured shape
- Four LED lamps with five brightness levels illuminate the viewed object
- Glare-free close-up field of view with 480 x 234 pixel display
- Automatically detects NTSC and PAL cameras
- Complete with rechargeable Lithium battery, and Universal AC adapter/charger with USB cable
Specifications
Camera
- Sensor size: ¼” CMOS
- Sensor pixels: 300,000
- Maximum frame rate: 30 FPS
- Color resolution: 24 Bit
- Focusing method: Fixed focus 15cm to 25cm (5.9″ to 9.8″)
- Gooseneck length: 1m (39″)
- Camera diameter: 17mm (0.66″)
- LCD Display: 2.4″ Color LCD
- Display resolution: 480 (W) X 234 (H) pixels
- Active area: 48mm x 35.6mm (1.9 x 1.4″)
- Light Source: 4 LEDs
- Adjustable light intensity: 6 illumination levels
- Video format: NTSC/PAL (automatic conversion)
- Power: Rechargeable 1800mAH lithium battery
- Current consumption: 400mA max.
- Standby current: 5mA max.
- Low battery warning: Voltage falls below 3.3V
Enviormental
- Operating Temperature: 32°F ~ 122°F (0°C ~ 50°C)
- Relative Humidity: 85% max.
BR50 is a Video borescope and camera tester with a 17mm camera diameter and 2.4 in. Color TFT LCD Monitor. Can also test installed surveillance cameras for correct target alignment. Applications include: Home inspection: Inspect in walls for mold, insect infestation, electrical wire or water pipe location; HVAC: Inspect inside ducts, behind motors and compressors; Automotive: View inside or around engines and transmissions; Government: Safety and security inspections; Industrial: Inspect weld integrity, process equipment, gears, molding machines; Aerospace: Aircraft inspections for contamination, debris, cracks or other damage. Comes complete with rechargeable Lithium battery, and Universal AC adapter and charger with USB cable.
