Description
General duty plus #25 stainless steel roller chain on 50ft reel sets its self above other roller chains by utilizing higher-precision components, high-quality 304-grade stainless steel, and ultra-high tensile strength. It’s made in accordance with ANSI B29.1 dimensional standards to ensure compatibility with other brands and sprockets. Buying #25SS stainless steel roller chain on a 50ft reel makes it possible to make specific cut-to-length strands without additional connection areas that can cause breakages down the line. For more information or to get a quote on stainless steel sprockets as well, please contact us, and we will be happy to assist you.
25 Stainless Steel Chain Dimensions
- Size: 25SS
- Pitch (P): 0.250″
- Roller Diameter (D1): 0.130″
- Width Between Inner Plates (B1): 0.125″
- Pin Diameter (D2): 0.091″
- Pin Length (LR): 0.36″
- Pin Length (LC): 0.46″
- Inner Plate Height (H2): 0.24″
- Plate Thickness (T): 0.030″
- Tensile Strength: 670 LBS
- Weight: 0.1 LBS/ FT
