Description
Features:
- Triple Channel, Max 1080W, Programmable Switching DC Power Supply
- Voltage combination – Channel 1: 30V | Channel 2: 30V | Channel 3: 30V
- Advanced web server: execute SCPI commands, control power supply through the server, data log, edit output sequence
- Size: 1/2 Rack 3U
- LAN, USB, and external analog remote control terminal communication interfaces
- Optional GPIB-USB adapter and RS232-USB available (sold separately)
- Adjustable rising and falling slew rate
- Output latency between channels with the same voltage module is less than 0.1ms
The Instek PSW-1080L111 is a triple-channel, wide-range output, programmable switching DC power supply. The maximum power is 1080W. Channels one, two, and three are rated for 30V output voltage and 36A output current.
The PSW-Multi series includes 37 models including 13 dual-channel models with a rated power of 720W, and 24 triple-channel models with a rated power of 1080W. The rated voltages of low-voltage modules are 30V, 40V, 80V, 160V. The rated voltages of high-voltage modules are 250V and 800V.
*The image is a representation of selection. See specifications for product details.
