Keysight 8473B Rf Detector – New In Sealed Packaging

Description

Features:

Superior RF Performance

• Frequency response: ±0.3 dB to 12.4 GHz, ±0.6 dB to 18 GHz
• Maximum SWR: 1.2 to 4 GHz, 1.5 to 18 GHz
• Low-level sensitivity: > 0.5 mV/uW
• Maximum operating input power: 200 mW
• Typical short-term maximum input power (< 1 minute): 1 W
• Noise: < 50 uV
• Output polarity: negative
• Input connector: 3.5 mm male

The Keysight 8473B Low-Barrier Schottky Diode (LBSD) detector has been widely used for many years in a variety of applications including leveling and power sensing. It offers good performance and ruggedness. Matched pairs (Option 001) offer very good detector tracking.
