Keysight (Agilent) 1134A Active Probe – Used, High-Fidelity Signal Capture

Description

Additional Features:

• Bandwidth: 7 GHz
• Dynamic Range: +/- 2.5V
• DC Offset Range: +/- 12V
• Maximum Voltage: +/- 30V
• Differential Input R: 50 kOhm
• Differential Input C: 0.27-0.34 pF
• Single Ended Input R: 25 kOhm
• Single Ended Input C: 0.44-0.67 pF

The Agilent 1134A InfiniiMax 7 GHz probe amplifier (in conjunction with the Agilent E2669A differential or Agilent HP E2668A single-ended connectivity kits), was designed to be used with the Infiniium 6 GHz Agilent 90604A oscilloscope. This combination provides a full system bandwidth of 6 GHz to the probe tip. InfiniiMax maximizes measurement performance for both hands-on (e.g., browsing) or hands-off measurements, such as solder-in, socketed or SMA connections.
