Description
Features:
- 4 channels / 500 MHz bandwidth
- Maximum sample rate: up to 4 GSa/s (all channels)
- 12-bit resolution (up to 16-bit in high resolution mode)
- Standard: parallel, RS232/UART, I2C, and SPI
- Standard interfaces: USB Device, USB Host, LAN, HDMI
- 10.1” touch screen (1280 x 800)
- 256-level intensity grading display, with digital real-time fluorescence technology
- This model does not have mixed signal analysis functionality (see MHO5000 for MSO usage)
Digital Oscilloscope (4 Channel / 500 MHz)
The Rigol DHO5000 series is a high-resolution digital oscilloscope designed to satisfy a variety of design, debugging, and testing requirements. Based on RIGOL’s brand new self-developed Centaurus platform, it features 12-bit resolution, with excellent noise floor and vertical measurement accuracy.
DHO5000 overview
DHO5000 models do not have logic analysis or waveform generation functionality.
Software options
Rigol offers a variety of software options for users to customize the oscilloscope to their specific application. Part numbers and descriptions can be seen below. Please note – parallel, RS232/UART, I2C, and SPI are included standard.
- DHO5000-AEROA – MIL-STD-1553
- DHO5000-AUDIOA – I2S
- DHO5000-AUTOA – CAN/CAN-FD, LIN
- DHO5000-BND – Software option bundle
- DHO5000-FlexA – FlexRay
- DHO5000-PWRA – Power Analysis
- DHO5000-SENTA – SENT
