Description
Features:
- 2 Channels – 0 to 32 V, Ch1 0 to 10 A, Ch2 0 to 5 A
- Ch1 160 W Max, Ch2 80 W Max (188 W Max total output power)
- Low residual ripple due to linear post-regulators
- Real-time voltage, current and watt values
- High setting and read-back resolution
- FuseLink (electronic fuse) freely combinable for all channels
- FuseDelay tunable up to 250 ms
- EasyArb function directly programmable at the device
- Free PC software to easily generate user-defined waveforms
- Independently adjustable over-voltage protection (OVP) for each channel
- Advanced parallel- and serial operation through V/I tracking
- Front connectors: 4 mm safety sockets
- Rear connectors for all channels including SENSE
- Optional USB/LAN Interface (HO732), RS-232/USB (HO720) or GPIB (HO740)
- CSA Safety Certified for USA (UL) and Canada (CSA)
The HMP power supplies are primarily designed for industrial use. With two, three or four output channels and up to 10 A output current per channel, these rugged instruments are ideal for a wide variety of applications. They offer high efficiency with low residual ripple and many protection functions.
- All channels galvanically isolated and floating
- All channels have the same voltage range
- All channels have overload and short-circuit protection
- Parallel and serial operation
- Constant voltage and constant current modes
- Tracking and link functions
- Protection functions to safeguard instrument and DUT
- Modern instrument concept: small, compact and quie
Easy operation
- Intuitive to use
- Color coding of operating states
- EasyArb function for all channels
- Save and recall instrument settings
Ideal for labs and test systems
- Tailored for use in labs and system racks
- Sense function for more stringent accuracy requirements
- Remote control of instrument functions
