Tektronix Dpo70804C Digital Oscilloscope – Pre-Owned High-Performance Model

Description

Features:

• Superior signal integrity and excellent signal-to-noise ratio – observe
• the truest representation of your waveform
• Pinpoint® triggering – minimize time spent trying to acquire problem
• signals for efficient troubleshooting and shortened debug time
• Visual Trigger – precisely qualify triggers and find unique events in
• complex waveforms
• Search and Mark – provides waveform or serial bus pattern matching
• and software triggers for signals of interest
• Automated Serial Analysis options for PCI Express, 8b/10b encoded
• serial data, I2C, SPI, CAN, LIN, FlexRay, RS-232/422/485/UART, USB
• 2.0, HSIC, MIL-STD-1553B, and MIPI® C-PHY, D-PHY and M-PHY
• P7700, P7600, and P7500 TriMode™ probing system – perfectly
• matched signal connectivity, with calibration to probe tip

Applications:

• Design verification including signal integrity, jitter, and timing analysis
• Design characterization for high-speed, sophisticated designs
• Certification testing of serial data streams for industry standards
• Memory bus analysis and debug
• Prototype turn-on and power supply verification
• Research and investigation of transient phenomena
• Production testing of complex systems
• Spectral analysis of transient or wide-bandwidth RF signals

Specifications:

• 8 GHz
• 4 Channel
• 50 S/s
• 500 MPts

The DPO70804C is a 8 GHz, 4 Channel, 50 S/s, 500 MPts digital oscilloscope from Tektronix.
