Tektronix P6015A High-Voltage Passive Probe (Refurbished)

Description

Additional Features:

• High Voltage – 20 kV DC / 40 kV Peak (100 ms Pulse Width)
• DC to 75 MHz
• Silicone Dielectric
• Nominal length: 3 m
• Attenuation: 1000X
• Bandwidth: 75 MHz
• Rise time (typ): 4.0 ns
• Loading: 100 MΩ/ 3.0 pF
• Maximum input voltage, DC or RMS: 20 kV
• Wide Compensation range (pf): 7 to 49
• Readout: No
• EMC environment and safety: UL3111-1, EN61010-1, IEC61010-2-031, CSA1010.1, CSA1010.2.031

Applications

• Power supply design
• Design motor drive
• Electronic ballast
• Power semiconductors
• Switch mode control
• UPS systems
• Power converters

For heavy-duty high-performance measurements of voltages over 2.5 kV, the P6015A is the industry standard. You can measure DC voltages up to 20 kVRMS and pulses up to 40 kV (peak, 100 ms duration). The 75 MHz bandwidth enables you to capture fast, high-voltage signals.

The P6015A uses an environmentally safe silicone compound for a dielectric and never needs refilling. Other features include: A 7-49 pF compensation range, small compensation box that fits on adjacent amplifier inputs, and a readout option for use with most Tektronix digital scopes. With the readout option, displayed voltage amplitude values will be the actual signal value rather than understated by a factor of 1,000.

Safe high voltage probe solutions for ground-referenced voltage testing. It is critical to safely and accurately capture real-time signal information from “elevated” or “floating” voltage systems. Our portfolio of high voltage probes provides the safety you need for single-ended, differential or isolated measurements.
