Description
UCF206-19 bearing is a 1-3/16″ bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 1-3/16″ shaft. UCF206-19 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior UCF206-19 bearing with a 1-3/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCF206-19 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set-screws. UCF206-19 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCF206-19 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCF206-19 bearings, and we will be happy to assist you!
UCF206-19 Bearing Dimensions
- Part #: UCF 206-19
- Shaft Diameter (d): 1-3/16″
- Dimension (A): 4.25″
- Dimension (E): 3.25″
- Dimension (I): 0.71″
- Dimension (G): 0.56″
- Dimension (L): 1.22″
- Dimension (S): 0.47″
- Dimension (Z): 1.56″
- Dimension (Bi): 1.5000″
- Dimension (N): 0.6260″
- Dimension (M): 0.8740″
- Bolt Used: 7/16
- Dynamic Load Rating (LBS): 4,377
- Static Load Rating (LBS): 2,569
- Bearing Insert: UC 206-19
- Housing Number: F 206
- Weight (LBS): 3.1
