Description
UEFCS208-24 bearing is a 1-1/2″ bore four-bolt normal-duty flange bearing that utilizes a Tru-Loc device to secure to a 1-1/2″ shaft and has an inch based housing. UEFCS208-24 flange cartridge bearings are designed for circumstances where the bearing is mounted to a surface that is perpendicular to the shaft axis. Our superior UEFCS208-24 bearing with a 1-1/2″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UEFCS208-24 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. UEFCS208-24 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UEFCS208-24 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UEFCS208-24 bearings, and we will be happy to assist you!
UEFCS208-24 Bearing Dimensions
- Part #: UEFCS208-24
- Shaft Diameter (d): 1-1/2″
- Dimension (A): 5.25″
- Dimension (P): 4.375″
- Dimension (E): 3.09″
- Dimension (I): 0.35″
- Dimension (S): 0.47″
- Dimension (J): 0.44″
- Dimension (K): 0.44″
- Dimension (G): 1.02″
- Dimension (F): 3.625″
- Dimension (Z): 1.28″
- Dimension (Bi): 1.9764″
- Dimension (N): 0.7480″
- Dimension (M): 1.1890″
- Bolt Used: 7/16
- Dynamic Load Rating (LBS): 6,634
- Static Load Rating (LBS): 4,079
- Bearing Insert: UE 208-24
- Housing Number: FCS 208
- Weight (LBS): 4.4
