Wayne Kerr 3245 Lcr Meter – Used Benchtop Analyzer

Description

Additional Features:

• Parameters: L, C, R, D, Q, Z, Angle ØRdc Turns Ratio
• AC-Stimulus Voltage (Programmable): 10 mV – 5V, 1mA – 100mA
• Other Features: Stimulus Voltage and Current Display
• DC Current: 1A max. Programmable, 20A x 3220A Bias Unit
• Frequency (Programmable): 20 to 300 kHz
• Basic Accuracy: 0.1%
• Display: 7″ Monitor, Parameter 5 digits
• Controls: Soft-keys plus keypad

The unit combines in a single, highly intelligent and interactive benchtop unit, the capability to drive, bias, and measure inductances at a wide range of frequencies up to 300 kHz. Associated series and parallel resistance and capacitances are measured simultaneously, and associated “minor terms” – Q, D, phase angle, ratio, DC resistance, and Z – are automatically computed from this measurement.
