Yokogawa Dl9240L Digital Oscilloscope – 1 Ghz Bandwidth, Used

Description

Additional Features:

• Bandwidth: 1.5 GHz
• Channels: 4
• Sample Rate: 5 GS/s, 10 GS/s Max
• Record Length: 6.25MW
• Input Coupling: AC, DC, GND, DC50Ω
• Trigger modes: Auto, Auto Level, Normal, Single, and N Single
• Up to 25,000 frames/sec/channel in continuous mode
• Up to 2.5 million frames/sec/channel in N Single mode
• With a partitioned large-capacity memory, the DL9000 can automatically accumulate and display up to 2,000 waveform frames

The Yokogawa DL9240L contains a wide array of analysis functions that include parameter statistics, trends, real time filters, serial bus analysis and power analysis. The DL9240L model has 6.25M points of waveform memory on each channel. In accumulate mode, the DL9240L overlays up to 2000 acquisitions on the screen that you can scroll through to look for signal peculiarities.
