Description
Features:
- Input channels CH1 to CH8(CH1 to CH7 when using logic input)
- Input coupling setting AC, DC, DC50 Ω, GND
- Input impedance 1 MΩ ±1.0%, approximately 20 pF 50 Ω ±1.0% (VSWR 1.4 or less, DC to 500MHz)
- Voltage axis sensitivity 1 MΩ 2 mV/div to 10 V/div (steps of 1-2-5)
- Setting range 50 Ω 2 mV/div to 500 mV/div (steps of 1-2-5)
- Max. input voltage 1 MΩ 150 Vrms 50 Ω Must not exceed 5 Vrms or 10 Vpeak
Yokogawa DLM4058 500 MHz Mixed Signal Oscilloscope 8-channel is a unique to the industry, mixed-signal oscilloscope suitable to test and debugging applications in the embedded systems, power electronics, mechatronics, and automotive sectors. The eighth input channel features Flex MSO which converts to a 8-bit logic analyzer at the push of a button; add sixteen additional logic analyzer inputs as an option, for 24-bit logic analysis. Advanced measurement and analysis features such as power analysis and serial-bus analysis, digital filtering, user-defined math, and super-long record lengths (up to 125 Mega Points) make the DLM4000 a super powerful engineering tool. High-resolution 12.1-inch LCD display, compact landscape format, ergonomic and friendly user-interface make it easy to use.
*Image is a Representation of Product; please see specifications for product details.
