Description
UCFX20-64 bearing is a 4″ bore four-bolt medium-duty flange bearing that utilizes set screws to secure to a 4″ shaft. UCFX20-64 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior UCFX20-64 bearing with a 4″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCFX20-64 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set-screws. UCFX20-64 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCFX20-64 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCFX20-64 bearings, and we will be happy to assist you!
UCFX20-64 Bearing Dimensions
- Part #: UCFX 20-64
- Shaft Diameter (d): 4″
- Dimension (A): 10.56″
- Dimension (E): 8.313″
- Dimension (I): 2.31″
- Dimension (G): 1.13″
- Dimension (L): 3.81″
- Dimension (S): 1.13″
- Dimension (Z): 5.00″
- Dimension (Bi): 4.6260″
- Dimension (N): 1.9370″
- Dimension (M): 2.3740″
- Bolt Used: 1
- Dynamic Load Rating (LBS): 29,339
- Static Load Rating (LBS): 23,141
- Bearing Insert: UCX 20-64
- Housing Number: FX 20
- Weight (LBS): 42.5
